Impel 1 HP 2 Pole IE2 3000 RPM B3 Foot Mounting 71 Frame 415V Three-Phase Squirrel Cage Induction Motor

Description

Impel 1 HP 2 Pole IE2 3000 RPM B3 Foot Mounting 71 Frame Three-Phase Squirrel Cage Induction Motor

The Impel 1 HP IE2 Efficiency Electric Motor is a robust and high-performance solution designed for demanding industrial applications. This three-phase squirrel cage induction motor operates at 2840 RPM (nominal) with a 2-pole configuration, making it ideal for high-speed operations in a wide range of machinery and equipment.

Built with a Totally Enclosed Fan Cooled ( T.E.F.C ) design and utilizing  IC 411 cooling, this motor is engineered for durability and long-term performance. It supports continuous duty (S1) and is suitable for ambient temperatures up to 50°C, ensuring reliable operation even in harsh environments.

With a frame size of 80 and B3 foot mounting, this motor is easy to install and compatible with a wide range of equipment setups. It runs on a standard 415 V ±10%, 50 Hz ±5% power supply and consumes 1.9 A of rated current. The motor offers excellent starting torque of 250%, making it well-suited for applications requiring high starting loads.

The IE2 energy efficiency rating ensures optimal power usage, with efficiency levels reaching up to 77.4%, helping reduce electricity consumption and operational costs over time.

Additional features include:

• Bidirectional rotation (CW & CCW) to suit various system requirements.

• High-quality 6204 ZZ C3 bearings on both ends for smooth, low-maintenance operation.

• V’Ring / Oil-seal sealing for improved protection against dust and moisture.

• Ingress protection rating of IP55, guarding against water jets and dust.

• Class F insulation for enhanced thermal stability and motor longevity.

• Weighs approximately 18 kg, offering a solid build without compromising ease of handling.

This motor is ideal for applications in industries such as manufacturing, processing, automation, and more. Whether you’re replacing an existing unit or building a new system, the Impel 1 HP motor provides the reliability and performance needed for continuous industrial use.
