Impel 1.5 HP 6 Pole IE2 930RPM B3 Foot Mounting 90 Frame 415V Motor

Impel 1.5 HP 6 Pole IE2 930RPM B3 Foot Mounting 90 Frame 415V Motor

Long Specifications :

This 1.5 HP (1.1 kW), 6-pole electric motor in frame size 90L is engineered for industrial applications that demand high torque at low speeds, offering a dependable and efficient power source for various types of machinery such as conveyors, crushers, agitators, and slow-speed fans.

Designed with a Totally Enclosed Fan Cooled (TEFC) enclosure and employing the IC 411 cooling method, the motor is well protected against dust, water jets, and external contaminants. The IP55 protection rating makes it suitable for harsh operating environments, while its insulation class F ensures thermal durability and longevity, especially under demanding temperature conditions up to 50°C.

Operating at a rated speed of 930 rpm with 6 poles, this motor is capable of both clockwise (CW) and counterclockwise (CCW) rotation, offering flexibility for reversible and bi-directional applications. It runs on a 415 V ±10%, 50 Hz ±5% power supply and is rated for continuous duty (S1), ensuring consistent performance over long operation periods.

Key electrical and performance characteristics include:

• Rated Current: 3.2 A
• Slip: 7.0%
• Rated Torque: 11.18 Nm
• Starting Current: 600% of rated current
• Breakaway Torque: 240%
• Breakdown Torque: 247%
• Service Factor: 1.00

This motor is also designed for energy-efficient operation with the following performance at different load levels:

• Efficiency: 77.00% (50% load), 77.50% (75% load), 78.10% (100% load)
• Power Factor: 0.50 (50%), 0.58 (75%), 0.60 (100%)

Mechanically, the motor is fitted with high-quality bearings—6205 ZZ C3 at the drive end and 6204 ZZ C3 at the non-drive end—to ensure smooth operation, reduced maintenance, and extended service life. The bearings are further protected by V’ Ring / Oil-seal sealing, which enhances durability and safeguards against lubricant leakage and contaminant ingress.

Weighing approximately 24 kg, this motor offers a compact and sturdy build with versatile mounting configurations B3 to accommodate a wide range of installation requirements. Its high torque, solid efficiency, and rugged construction make it a reliable choice for demanding industrial applications where consistent, low-speed performance is critical.
