Showing 229–240 of 533 results
-
Sale!
₹93,814 Original price was: ₹93,814.₹44,100Current price is: ₹44,100. Basic
Impel 20HP 6 Pole IE2 2900RPM B3 Foot Mounted 160MFrame 415V Motor
Specifications :
- Frame Size: 160M
- Cooling Method: IC 411 (TEFC)
- Output Power: 20.0 HP / 15.0 kW
- Mounting Type: B3
- Number of Poles: 2
- Rotation: Clockwise (CW) & Counter-Clockwise (CCW)
- Frequency: 50 Hz ±5%
- Rated Voltage: 415 V ±10%
- Rated Current: 27.2 A
- Duty Cycle: S1 (Continuous)
- Insulation Class: F
- Ambient Temperature: 50°C
- Rated Speed: 2900 rpm
- Slip: 3.3%
- Starting Current: 700% of rated current
-
Sale!
₹98,750 Original price was: ₹98,750.₹46,400Current price is: ₹46,400. Basic
Impel 20HP 4 Pole IE2 1450RPM B3 Foot Mounted 160LFrame 415V Motor
Specifications :
- Frame Size: 160L
- Cooling Method: IC 411 – TEFC
- Output Power: 20.0 HP / 15.0 kW
- Mounting Type: B3
- Number of Poles: 4
- Rotation Direction: CW & CCW
- Frequency: 50 Hz ±5%
- Voltage: 415 V ±10%
- Duty Cycle: S1 (Continuous)
- Rated Current: 28.0 A
- Ambient Temperature: 50°C
- Rated Speed: 1450 rpm
- Insulation Class: F
- Protection Degree: IP55
- Slip: 3.3%
-
Sale!
₹99,324 Original price was: ₹99,324.₹49,000Current price is: ₹49,000. Basic
Impel 25.0 HP 2 Pole IE2 2910 RPM B5 Flange Mounted 160 Frame 415V Three-Phase Squirrel Cage Induction Motor
Specifications :
- Frame Size: 160L
- Output Power: 25 HP / 18.5 kW
- Poles: 2
- Speed: 2910 RPM
- Cooling Method: IC 411 – TEFC
- Mounting: B5
- Rated Voltage: 415 V ±10%
- Frequency: 50 Hz ±5%
- Rated Current: 33.1 A
- Insulation Class: F
- Duty Cycle: Continuous (S1)
- Ambient Temperature: 50°C
- Protection Class: IP55
- Rotation: CW & CCW (Both directions)
- Slip: 3.0%
-
Sale!
₹99,324 Original price was: ₹99,324.₹46,700Current price is: ₹46,700. Basic
Impel 25HP 2 Pole IE2 2910RPM B3 Foot Mounted 160LFrame 415V Motor
Specifications :
- Frame Size: 160L
- Cooling Method: IC 411 (TEFC)
- Output Power: 25.0 HP / 18.5 kW
- Mounting Type: B3
- Number of Poles: 2
- Rotation: Clockwise (CW) & Counter-Clockwise (CCW)
- Frequency: 50 Hz ±5%
- Rated Voltage: 415 V ±10%
- Rated Current: 33.1 A
- Duty Cycle: S1 (Continuous)
- Insulation Class: F
-
Sale!
₹23,135 Original price was: ₹23,135.₹10,900Current price is: ₹10,900. Basic
Impel 3 HP 4 Pole IE2 1430 RPM B5 Flange Mounted 100 Frame 415V Three-Phase Squirrel Cage Induction Motor
Specifications :
- Frame Size: 100L
- Output Power: 3.0 HP / 2.2 kW
- Poles: 4
- Rated Speed: 1430 RPM
- Cooling Method: IC 411 – TEFC
- Mounting: B5
- Rated Voltage: 415 V ±10%
- Frequency: 50 Hz ±5%
- Rated Current: 4.7 A
- Insulation Class: F
- Duty Cycle: Continuous (S1)
- Ambient Temperature: 50°C
- Protection Degree: IP55
- Rotation: Clockwise & Counterclockwise (CW & CCW)
- Slip: 4.66%
- Service Factor: 1.00
-
Sale!
₹21,029 Original price was: ₹21,029.₹9,900Current price is: ₹9,900. Basic
Impel 3.0 HP 2 Pole IE2 2850 RPM B5 Flange Mounted 90 Frame 415V Three-Phase Squirrel motor
Specifications :
- Frame Size: 90L
- Output Power: 3.0 HP / 2.2 kW
- Poles: 2
- Rated Speed: 2850 rpm
- Rated Torque: 7.36 Nm
- Rated Voltage: 415 V (±10%)
- Rated Current: 4.0 A
- Frequency: 50 Hz (±5%)
- Duty Cycle: S1 (Continuous)
- Cooling Method: IC 411 – TEFC
- Mounting Type: B5
- Rotation: Clockwise & Counter-clockwise (CW & CCW)
- Insulation Class: F
- Protection Degree: IP55
- Ambient Temperature: Up to 50°C
- Slip: 5.5%
-
Sale!
₹31,191 Original price was: ₹31,191.₹14,650Current price is: ₹14,650. Basic
Impel 3.0 HP 6 Pole IE2 940 RPM B5 Flange Mounted 112 Frame 415V Three-Phase Squirrel motor
Specifications :
- Frame Size: 112M
- Cooling Method: IC 411 (TEFC)
- Output Power: 3.0 HP / 2.2 kW
- Mounting Type: B3
- Number of Poles: 6
- Rotation Direction: CW & CCW
- Frequency: 50 Hz ±5%
- Voltage: 415 V ±10%
- Duty Cycle: S1 (Continuous)
- Rated Current: 5.4 A
- Ambient Temperature: 50°C
- Rated Speed: 940 rpm
- Insulation Class: F
- Protection Degree: IP55
- Slip: 6.0%
-
Sale!
₹20,416 Original price was: ₹20,416.₹20,400Current price is: ₹20,400. Basic
Impel 3.0HP 2Pole IE2 2850RPM B3 Foot Mounted 90L Frame 415V Motor
Specifications :
- Frame Size: 90L
- Output Power: 3.0 HP / 2.2 kW
- Poles: 2
- Rated Speed: 2850 rpm
- Rated Voltage: 415 V ±10%
- Rated Current: 4.0 A
- Frequency: 50 Hz ±5%
- Cooling Method: IC 411 (TEFC)
- Mounting: B3
- Rotation: Clockwise & Counterclockwise (CW & CCW)
- Insulation Class: F
- Duty Cycle: Continuous (S1)
- Ambient Temperature: 50 ºC
- Protection Degree: IP55
- Slip: 5.5%
- Starting Current: 700%
- Rated Torque: 7.36 Nm
- Breakaway Torque: 250%
- Breakdown Torque: 280%
- Service Factor: 1.00
-
Sale!
₹30,283 Original price was: ₹30,283.₹14,250Current price is: ₹14,250. Basic
Impel 3.0HP 6Pole IE2 940RPM B3 Foot Mounted 112MFrame 415V Motor
Specifications :
- Frame Size: 112M
- Cooling Method: IC 411 (TEFC)
- Output Power: 3.0 HP / 2.2 kW
- Mounting Type: B3
- Number of Poles: 6
- Rotation Direction: CW & CCW
- Frequency: 50 Hz ±5%
- Voltage: 415 V ±10%
- Duty Cycle: S1 (Continuous)
- Rated Current: 5.4 A
- Ambient Temperature: 50°C
- Rated Speed: 940 rpm
- Insulation Class: F
- Protection Degree: IP55
- Slip: 6.0%
-
Sale!
₹29,497 Original price was: ₹29,497.₹13,900Current price is: ₹13,900. Basic
Impel 3.7 KW 5.0HP 4 Pole IE2 1440 RPM B3 Foot Mounted 112M Frame 415V Motor
Specifications :
- Frame Size: 112M
- Cooling Method: IC 411 – TEFC (Totally Enclosed Fan Cooled)
- Output Power: 5.0 HP / 3.7 kW
- Mounting Type: B3
- Poles: 4
- Rotation: Both Clockwise (CW) & Counter-Clockwise (CCW)
- Frequency: 50 Hz ±5%
- Insulation Class: F
- Rated Voltage: 415 V ±10%
- Duty Cycle: Continuous (S1)
- Rated Current: 7.2 A
- Ambient Temperature: 50 ºC
- Rated Speed: 1440 rpm
- Protection Degree: IP55
- Slip: 4%
-
Sale!
₹28,836 Original price was: ₹28,836.₹13,550Current price is: ₹13,550. Basic
Impel 5 HP 2 Pole IE2 2850 RPM B5 Flange Mounted 100 Frame 415V Three-Phase Squirrel Cage Induction Motor
Short specification:
- Frame Size: 100L
- Output Power: 5.0 HP / 3.7 kW
- Poles: 2
- Speed: 2850 rpm
- Voltage: 415 V ±10%
- Frequency: 50 Hz ±5%
- Current: 7.0 A
- Torque (Rated): 12.16 Nm
- Mounting Type: B5
- Rotation: Clockwise (CW) & Counterclockwise (CCW)
- Cooling Method: IC 411 – TEFC
- Insulation Class: F
- Duty Cycle: Continuous (S1)
- Ambient Temp.: 50°C
- Protection Degree: IP55
- Slip: 5%
-
Sale!
₹30,382 Original price was: ₹30,382.₹14,300Current price is: ₹14,300. Basic
Impel 5 HP 4 Pole IE2 1440 RPM B5 Flange Mounted 112 Frame 415V Three-Phase Squirrel Cage Induction Motor
Specifications :
- Frame Size: 112M
- Output Power: 5.0 HP / 3.7 kW
- Poles: 4
- Rated Speed: 1440 RPM
- Cooling Method: IC 411 – TEFC
- Mounting Type: B5
- Rotation: CW & CCW (Both directions)
- Rated Voltage: 415 V ±10%
- Frequency: 50 Hz ±5%
- Rated Current: 7.2 A
- Starting Current: 650%
